Lapping Film Range — Rolls, Sheets & Discs
Diamond Lapping Film
AO / CO Lapping Film
Microfinishing Film Rolls
Polishing Tapes & Flocked Films
Grades: 0.5 / 1 / 3 / 9 / 15 / 30 μm · Backings: PSA & plain · Formats: rolls, sheets, discs & custom sizes
Lapping Film Product Line — Full Specifications
Diamond Lapping Film — 0.5 to 30 Micron
Monocrystalline and polycrystalline diamond lapping film for the hardest materials: fiber optic connector endfaces, ceramics, sapphire and tungsten carbide. Tight particle-size distribution keeps scratch depth predictable from batch to batch — the reason connector factories standardize on diamond film for final polish. 1 micron lapping film and 3 micron diamond lapping film sheets and discs are stocked for fast shipment.
| Abrasive | Monocrystalline / polycrystalline diamond |
| Micron grades | 0.5, 1, 2, 3, 6, 9, 15, 16, 30, 40, 45, 60, 80 μm (#10000 to #180) |
| Backing | Polyester film, with or without backing |
| Formats | Sheets, discs and rolls |
| Typical applications | Fiber optic connectors, ceramics, carbide, sapphire |
Aluminum Oxide & Cerium Oxide Lapping Film
Aluminum oxide lapping film (AO) covers general lapping and pre-polish from 0.3 to 30 micron; cerium oxide film (CO) delivers the final optical-grade finish on glass. Together they form the standard sequence for optical component lapping, metallography and fiber polishing where diamond is not required — at a significantly lower cost per polish step.
| Abrasive | Aluminum oxide (AO) / cerium oxide (CO) / silicon carbide (SiC) |
| Micron grades | AO 0.3 to 40 μm (11 grades) · SiC 1 to 30 μm (7 grades) · CO 0.3 and 0.5 μm only |
| Backing | Polyester film, with or without backing |
| Formats | Sheets, discs, rolls |
| Typical applications | Optical glass, lenses, metallographic prep, fiber optics |
Microfinishing Film Rolls for Production Lines
Precision microfinishing film (microfinishing paper) in continuous rolls for camshaft, crankshaft, printing roller and shaft superfinishing lines. Engineered for consistent cut rate and surface finish (Ra) over long production runs on automated microfinishing equipment — roll widths slit to match your machine.
| Abrasive | Aluminum oxide / silicon carbide / diamond |
| Micron grades | 9, 15, 20, 30, 40, 60 μm |
| Roll widths | Slit to machine spec (custom) |
| Formats | Continuous rolls |
| Typical applications | Camshaft & crankshaft finishing, rollers, shafts |
Polishing Tapes & Flocked Pile Films
Fine polishing tape and flocked pile polishing film for fiber optic connector endface cleaning and polish, MPO/MTP arrays and 3C electronics. Flocked pile structure carries slurry evenly for a haze-free final surface — paired with our diamond films as a complete connector polishing consumables set.
| Type | Fine polishing tape / flocked pile film / cleaning rollers |
| Micron grades | 0.5–9 μm (tape), pile for slurry polish |
| Backing | PSA or plain |
| Formats | Tapes, rolls, sheets |
| Typical applications | Fiber connector endface, MPO/MTP, 3C electronics |
All grades available with PSA (pressure-sensitive adhesive) or plain polyester backing. Custom widths, lengths, die-cut disc shapes and private-label converting on request.
A Real Factory, Not a Trading Company
GRISH has manufactured precision abrasives since 2002 in a 12,000 m² factory & laboratory with imported coating and converting equipment. Over 20 years of joint R&D with universities turned research projects into 49 invention patents — and GRISH co-authored 5 industry standards for polishing materials. Films are coated, converted and inspected in-house, so consistency and lead time stay under our control, not a middleman’s.
- ISO9001 quality command across man, machine, material, method & environment
- Imported production equipment · 100+ technicians, half with 5–10 years tenure
- 20+ years university joint R&D · 49 patents · 5 industry standards co-authored
- 3,000+ customers, 9,000+ polishing solutions across 12 industries
Certified: ISO 9001 quality · ISO 14001 environmental · ISO 45001 occupational safety
| What buyers compare | GRISH (factory-direct) | Typical trading company |
|---|---|---|
| Custom grades, widths & die-cut | Made on our own lines to your spec | Limited to whatever stock exists |
| Batch consistency & traceability | In-house coating, QC records per batch | Varies by whichever factory supplied |
| Technical support | R&D engineers who formulate the abrasives | Sales reps relaying questions |
| Lead time control | Production schedule under our control | Dependent on upstream factories |
| Price structure | Factory price, no middle layer | Factory price + trader margin |
From Specs to Samples in 3 Steps
1. Send Your Specs
Application, micron grade, format and estimated quantity — or just describe your process if unsure.
2. Engineer Review & Quote
Our application engineers confirm the right film and send a factory-direct quotation within 24 hours.
3. Free Sample & Trial Order
Qualified B2B buyers receive free samples. Validate on your line before committing to volume.
Built for Your Application
Fiber Optic & MPO Connector Polishing
Optical Component Lapping
Semiconductor & Electronics
Fiber Optic LED & Semiconductor Optical Glass LCD Panel Automobile Industrial Roller Metal Parts Ceramics & Precious Materials Metallography Micro Motor 3C Electronics Dental
Why Global Buyers Choose GRISH
3,000+
Value customers served worldwide
9,000+
Industry polishing solutions delivered
49
Invention patents · co-author of 5 industry standards
200+
Employees incl. 100+ production technicians
Frequently Asked Questions
Yes. Share your workpiece material, process stage, target surface finish and machine type — our application engineers will recommend the grade and format within 24 hours.
Yes. Custom micron grades, backings (PSA or plain), widths, lengths and die-cut disc shapes are available. OEM/ODM orders are welcome.
Trial orders are welcome, and free samples are available for qualified B2B buyers — just tell us your application when you send the RFQ.
We ship worldwide from our 12,000 m² factory in China. Standard products ship quickly; custom specifications are quoted with clear production lead times.
Common B2B terms are supported — T/T and other standard arrangements, with EXW / FOB / CIF trade terms quoted per your destination.
Standard grades and formats ship quickly from factory stock; custom specifications are quoted with a clear production lead time before you commit.
